WS-2x2-40W | 120-277V | 5W | 5CCT LED Panel Light

No.SYN-2x2-40W-5CCT

WEISS 2x2ft LED PANEL LIGHT 120-277V 40W 5CCT

Voltage Rating
120-277V, 50/60Hz
Wattage
20W/25W/30W/35W/40W Selectable
Color Temperature (CCT)
2700K/3000K/3500K/4000K/5000K Selectable
Lumens
125Lm/W, up to 5,000Lm
Dimming
0-10V
Color Rendering Index (CRI)
>80
Lamp Type
LED
Housing Material
Aluminum casing
Lens Type
Flat Opal
Dimensions
2 ft x 2 ft
IP Rating
IP20
Average Life
~50,000 hours
Operating Temperature
-25°C~40°C (-13°F~104°F)
Mounting Type
Recessed mount in plaster or grid ceilings / surface mount with surface kit (sold separately)
Options
Emergency backup battery / Surface Mount Kit / Motion sensor
Standards
cETLus Listed, DLC Premium Listed

Description

The Selectable backlit panel is a highly versatile luminaire designed to provide five lumen and five CCT packages per size. Available for use in recessed, suspended, and surface mount applications, the SBP is a versatile luminaire that is ideal for general lighting applications such as open office, schools, healthcare, and retail.

Documents  Specification
